FEATURED 2027 PJ Trailers 83 in Telescopic Dump (DT1) - 14502PJ
Get in Touch
AT A GLANCE
LOW PRO TELESCOPIC DUMP TRAILER BUMPER PULL 2-5/16" ADJUSTABLE- DEMCO EZ- LATCH 2-7000# ELECTRIC / SPRING SPLIT / SPREADER GATE PIRMER + BLACK POWDER COAT
Industry
Trailer
Make
PJ Trailers
Category
Dump Trailer
Year
2027
Model
83 in Telescopic Dump (DT1)
Trim
Base
Stock
14502PJ
Subcategory
Dump Trailer
Description
2027 PJ Trailers 83 in Telescopic Dump (DT1)
83" Telescopic Dump (DT1)
The future is here with the all-new DT, a revolutionary dump trailer that redefines industry standards.
The redesigned DT is a powerful dump trailer with 5-Stage Front-Mount Telescopic Cylinder technology, handling heavy loads with ease. The front-positioned cylinder improves accessibility, while the 45° bed angle speeds up unloading. The next-gen PJ dump body features Monster Rails for 30% more strength, and the Demco EZ-Latch and Monster-Sized Toolbox offer added convenience. The 4' side version hauls up to 16.3 yd³ of materials, built for performance and longevity.
What Drives You, Drives Us™
5-STAGE FRONT-MOUNT TELESCOPIC
The future of lifting technology handles loads with ease, and the cylinder is up front to be out of the way during use and easy for maintenance.
IMPROVED DUMP ANGLE
With the new cylinder technology, combined with the 45° bed angle and front design, the DT gets your aggregate out quicker and more efficiently.
MONSTER RAILS
The next generation of PJ dump bodies is capped off by a new rail design that provides strength (2x) than a traditional top rail.
4' HIGH SIDE AVAILABLE
For applications that need to haul additional volume, the 4' side version hauls up to 14 yd3 of landscape or construction materials.
Dealer Notes
LOW PRO TELESCOPIC DUMP TRAILER
BUMPER PULL 2-5/16" ADJUSTABLE- DEMCO EZ- LATCH
2-7000# ELECTRIC / SPRING
SPLIT / SPREADER GATE
PIRMER + BLACK POWDER COAT
Info
Condition
New
Location
Bonander Trailer - Turlock
VIN
4P51D1425V1439535
Dry Weight
4060
Color
BLACK
Hitch Type
BUMPER PULL
Axles
2
Length
14
Width
83 in
Rear Door
SPLIT / SPREADER GATE
Gvwr
15400
Axle Capacity
7000#
Payload Capacity
11340
Specifications
Axles
[72BS] (2) 7,000# Electric / Spring | Options: [72BD] (2) 7,000# Electric / Drop Axle | Options: [82BS] (2) 8,000# Oil Bath w/14 Ply LR-G Tires Electric / Spring | Options: [92BS] (2) 7,000# w/14 Ply LR-G Tires Electric / Spring | Options: [92BD] (2) 7,000# w/14 Ply LR-G Tires Electric / Drop Axle | Options: [K2BS] (2) 8,000# Oil Bath w/215/75R17.5 LR-H Singles Electric / Spring | Options: [Y2BS] (2) 7,000# w/215/75R17.5
Suspension
6-Leaf Slipper Spring Suspension
Tongue
8 in x 13 lb. I-beam Tongue
Coupler
[J] BP 2-5/16 in Adjustable- Demco EZ-Latch | Options: [P] 3" Pintle Eye - Channel-Mount (20,000 lb.) | Options: [T] BP 2-5/16" Adjustable Coupler (20,000 lb.) w/HD 6-Hole Channel Bracket
Notes
Jack: Drop Leg Jack (12,000 lb.) | Jack - Options: [-JA05] 1 Hydraulic Jack (BP Only) | Jack - Options: [-JA17] Single 2-speed Jack (12,000 lb.) (BP Only) | Stake Pockets: Stake Pockets on Both Sides (Quantity Varies by Length) | Wiring: All-Weather Wiring Harness (7-way RV) | Spare Tire - Options: [-SP01] Spare Tire (Default Tire) | Spare Tire - Options: [-SP09] Spare Tire Option 215/75/17.5 (H) SNG BLK Mod (TW21575R1758SBM) | Spare Tire - Options: [-SP18] Spare Tire Option 235/80R16 14ply SNG BLK Mod (TW23580R168SLRGBM) | Tie-Downs: (4) D-Rings (Welded inside the Box) | Options - Tie-Downs: [-DR01] 1 Extra Pair D-Rings | Stabilizers: Rear Stabilizer Stands | Tarp: Roll-up Tarp Kit (Pull Bar) 7 ft x 20 ft | Other Options: [-VYGR] Solar Charger, Swing Arm Tarp, Hydraulic Jack, 14Ply tires | Pull Type: Bumperpull
Frame
8 in x 13 lb. I-Beam Main Frame
Crossmembers
3 in Channel Crossmembers 16 in oc
Floor
7ga. Steel Bed
Fenders
1/8 in Treadplate Steel Fenders
Ramps
6 ft 5 in Slide-In Channel Ramps
Tires
ST235/80R16 Radial Tires 10 ply (3,520 lbs.)
Finish
Paint Color: [K] Primer + Black Powder Coat | Options: [1] Primer + Red Powder Coat | Options: [3] Primer + White Powder Coat | Options: [5] Primer + Tractor Orange Powder Coat | Options: [6] Primer + Grey Powder Coat | Options: [8] Primer + Desert Tan Powder Coat | Options: [B] Primer + Jet Blue Coat (NEW!) | Options: [J] Primer + Industrial Green Coat (NEW!) | Options: [Y] Primer + Industrial Yellow Coat (NEW!) | Options: [G] Primer + Slime Green Coat (NEW!)
Battery
12V Deep Cycle Battery | Options: [-BYEB] 1 Extra Battery | Options: [-BYSL] Solar Battery Charger
Walls
Sides: 24 in 10ga. Steel Sides w/ Monster Rails | Options: [-SW04] 4ft Tall Sides
Step
Treadplate Step (Both Sides)
Gate/Door
Dump: 2-Way Gate (Barn Doors & Spreader Gate) | Tail: [T] Split / Spreader Gate
GVWR
15400 lbs | Options: [-GV09] 9,900 G.V.W.R.
Dry Weight
3980 lbs
Length
Bed: 14 ft | Tongue: 4 ft 10 in (58 in)
Width
Bed: 83 in
