FEATURED 2027 PJ Trailers 8 in I-Beam Equipment Tilt (TY) 22 ft- 14641PJ
Get in Touch
AT A GLANCE
Industry
Trailer
Make
PJ Trailers
Category
Tilt Trailer
Year
2027
Model
8 in I-Beam Equipment Tilt (TY)
Trim
22 ft
Stock
14641PJ
Subcategory
Tilt Trailer
Description
2027 PJ Trailers 8 in I-Beam Equipment Tilt (TY) 22 ft
8" I-Beam Equipment Tilt (TY)
Push your hauling limits further with the TY I-Beam Tilt Trailer, utilizing a 12-degree tilt and a strong I-Beam frame for superior capacity and versatility.
Engineered for professional-grade performance and high-capacity hauling, the PJ Trailers TY I-Beam Tilt Trailer is built to support your heaviest machines and attachment-heavy setups with confidence. With its ultra-strong I-Beam frame, smooth 12-degree tilt geometry, and integrated features like fork pockets and a full tongue toolbox, it provides the structural strength and organization needed for repeated loading cycles. For those who are passionate about their work and require a trailer that reduces compromise in daily operations, the TY is the ultimate tool for conquering the jobsite.
What Drives You, Drives Us™
SEAMLESS I-BEAM FRAME
The TY tilt trailer is built on a robust I-beam main frame. Designed to minimize frame flex while maximizing towing stability, this heavy-duty construction ensures the trailer performs reliably under tough working conditions and heavy equipment loads.
INTEGRATED FORK POCKETS
Built-in fork pockets designed to securely store forklift forks during transport. This thoughtful feature helps keep loose equipment contained and organized, making it easier to manage attachments while on the move.
HYDRAULIC DAMPENED TILTING DECK
The tilt deck features hydraulic dampening for smooth and controlled operation. The dampening system slows the deck as it lowers, helping prevent hard impacts and providing safer, more predictable loading and unloading.
FULL TONGUE TOOLBOX
A full-width tongue toolbox provides secure, convenient storage for essential gear such as a spare tire, chains, and tools. This enclosed storage space helps keep equipment organized and protected while maximizing usable deck space.
Info
Condition
New
Location
Bonander Trailer - Turlock
Availability
Available
VIN
4P51C2226V1444786
Dry Weight
4365
Color
BLACK
Hitch Type
BUMPER PULL
Axles
2
Length
22
Gvwr
17600
Axle Capacity
2-8000lb
Payload Capacity
13235
Hitch Ball Size
2-5/16in
Specifications
Axles
[72BT] (2) 7,000# Electric / Torsion | Options: [82BT] (2) 8,000# Oil Bath w/14 Ply LR-G Tires Electric / Torsion | Options: [92BT] (2) 7,000# w/14 Ply LR-G Tires Electric / Torsion | Options: [K2BT] (2) 8,000# Oil Bath w/215/75R17.5 LR-H Singles Electric / Torsion | Options: [Y2BT] (2) 7,000# w/215/75R17.5 LR-H Singles Electric / Torsion
Suspension
Torsion Suspension
Tongue
8 in I-beam Tongue
Coupler
[J] BP 2-5/16 in Adjustable (14,000lb) | Options: [P] 3 in Pintle Eye - Channel-Mount | Options: [T] BP 2-5/16 in Adjustable Coupler (20,000 lb) w/HD 6-Hole Channel Bracket
Safety Chains
3/8 in Grade 70 w/ Safety Latch Hook (2 ea)
Notes
Jack: 12,000# Drop-Leg Jack (Side Wind) | Options - Jack: [-JA05] 1 Hydraulic Jack (BP Only) | Stake Pockets: 24 in Stake Pocket Spacing | Wiring: All-Weather Wiring Harness (7-way RV) | Tilt Deck Operation: Hydraulic Dampening With Deck Locking | Rubrail: Rubrail & Stake Pockets | Hydraulics: Hydraulic - Cushioned Gravity tilt | Storage: Full-Tongue Locking Toolbox w/ Exterior Lashing Points | Winch - Options: [-WN01] Plate for Winch (BP Only) | Winch - Options: [-WN03] Winch Plate w/ Welded Receiver Hitch | Winch - Options: [-WN12] Winch 12.5K w/Plate & Battery | Winch - Options: [-WN95] Winch 10k w/ Plate & Battery | Winch - Options: [-WNFR] Roller on Front of Deck for Winch Cable | Pipe Chain Spools: Pipe Spools | Tilt Deck Angle. 12 Degrees | Lift Cylinder: 3 in x 16 in Cylinder | Other Options: [-TRA1] 1/2 x 1/2 Square Traction Bars | Pull Type: Bumperpull | Payload Capacity: 11050 lbs
Frame
8 in x 10 lb. I-Beam Main Frame
Crossmembers
3 in Crossmembers on 16 in Centers | Options: [-CM12] 12 in OC Crossmembers
Floor
2 in Treated Pine Lumber Deck | Options: [-FLRO] Rough Oak Floor | Options: [-FLNF] No Flooring
Fenders
9 in x 72 in Treadplate Removable Steel Fenders
Tires
ST235/80R16 Radial Tires 10 ply (3,520 lbs.)
Finish
Paint Color: [K] Primer + Black Powder Coat | Options: [1] Primer + Red Powder Coat | Options: [3] Primer + White Powder Coat | Options: [5] Primer + Tractor Orange Powder Coat | Options: [6] Primer + Grey Powder Coat | Options: [8] Primer + Desert Tan Powder Coat | Options: [B] Primer + Jet Blue Coat (NEW!) | Options: [J] Primer + Industrial Green Coat (NEW!) | Options: [Y] Primer + Industrial Yellow Coat (NEW!) | Options: [G] Primer + Slime Green Coat (NEW!)
D-Rings
Tie-Downs: (6) D-rings | Options: [-RT01] 1 Pair Weld-On Ratchets | Options: [-DR01] 1 Extra Pair D-Rings
Electrical
Breakaway System: Electric Breakaway System w/ Charger
Battery
Options: [-BYSL] Solar Battery Charger
GVWR
15400 lbs | Options: [-GV09] 9,900 G.V.W.R.
Dry Weight
4350 lbs
Length
Deck: 22 ft | Tongue: 60 in
Width
Deck: 83 in
